12.5 inch Planer with BYRD Cutterhead 2HP 15A 1Ph | 15 inch Planer with Helical Cutterhead 3HP 1Ph | 20 inch Planer with Helical Cutterhead 5HP 1Ph | 22 inch Planer with 4 Knife HSS Straight Cutterhead 7.5HP 1Ph |
22 inch Planer with 4 Knife HSS Straight Cutterhead 10HP 3Ph | 22 inch Planer with Byrd Shelix Cutterhead 7.5HP 1Ph | 22 inch Planer with Byrd Shelix Cutterhead 10HP 3Ph | 25 inch Planer with 4 Knife HSS Straight Cutterhead 10HP 1Ph |
25 inch Planer with 4 Knife HSS Straight Cutterhead 15HP 3Ph | 25 inch Planer with Byrd Shelix Cutterhead 10HP 1Ph | 25 inch Planer with Byrd Shelix Cutterhead 15HP 3Ph |
Models | |
---|---|
12.5 inch Thickness Planer | |
10044.201 | 12.5 inch Planer with BYRD Cutterhead 2HP 15A 1Ph |
15 inch Planer | |
10014.201 | 15 inch Planer with Helical Cutterhead 3HP 1Ph |
20 inch Planer | |
4430.201 | 20 inch Planer with Helical Cutterhead 5HP 1Ph |
22 inch Planer | |
4455.001 | 22 inch Planer with 4 Knife HSS Straight Cutterhead 7.5HP 1Ph |
4455.002 | 22 inch Planer with 4 Knife HSS Straight Cutterhead 10HP 3Ph |
4455.103B | 22 inch Planer with Byrd Shelix Cutterhead 7.5HP 1Ph |
4455.104B | 22 inch Planer with Byrd Shelix Cutterhead 10HP 3Ph |
25 inch Planer | |
4470.001 | 25 inch Planer with 4 Knife HSS Straight Cutterhead 10HP 1Ph |
4470.002 | 25 inch Planer with 4 Knife HSS Straight Cutterhead 15HP 3Ph |
4470.101B | 25 inch Planer with Byrd Shelix Cutterhead 10HP 1Ph |
4470.102B | 25 inch Planer with Byrd Shelix Cutterhead 15HP 3Ph |
PLANER OPTIONAL ACCESSORIES | |
A-BYRD 10 | BYRD Shelix Helical Inserts (pack of 10) |
P-BYRD SCREW | Screw for Byrd Insert (each) |
P-15MM 4S | 4 Side Inserts (pack of 10) will not fit BYRD 4225|4235|4265C|4275C|4420|4430|10014 |
P-30MM TCT | 2 Side TCT Helical Inserts (pack of 10) |
P-038201-101 | Torx Screw (for P-15mm 4S) - Used on 4225|4235|4265C|4275C|4420|4430|10014 |
4455.A001 | 22 inch Replacement Straight Knives HSS (4) |
4470.A001 | 25 inch Replacement Straight Knives HSS (4) |
12-1/2 inch Thickness Planer - 10044
ALL THE BELLS AND WHISTLES
Features
|
Specifications | |
---|---|
Model Number | 10044 |
CutterHead | Byrd Shelix |
Ph | 1Ph |
Stock Number | 10044.201 |
Maximum Stock Width | 12-1/2 inch |
Maximum Depth of Cut | 5/64 inch and 3/64 inch |
Maximum Stock Thickness | 6 inch |
Minimum Stock Thickness | 5/32 inch |
Minimum Stock Length | 5 inch |
Dust Port Diameter | 2.5 inch or 4 inch |
Feed Speeds | 26 FPM |
Table Size | 12-1/2 inch x 10-5/16 inch |
Table Size w/Extension Wings | 12-1/2 inch x 33-3/16 inch |
Cutterhead Diameter | 1-7/8 inch |
Cutterhead Speed | 10,000 |
Number of Knives | 36 |
Number of Knives Byrd | 36 |
Motor | 2HP 15A 115V |
Motor 1Ph | 2HP 15A 115V |
Net Weight | 68 |
Gross Weight | 75 |
15 inch Planer with Helical Cutterhead - 10014
|
Specifications | |
---|---|
Model Number | 10014 |
Stock No. (3HP, 1Ph) | 10014.201 |
Stock Number | 0 |
Maximum Stock Width | 15 inch |
Maximum Depth of Cut | 1/8 inch |
Maximum Stock Thickness | 6 inch |
Minimum Stock Thickness | 3/16 inch |
Minimum Stock Length | 6 inch |
Dust Port Diameter | 4 inch |
Feed Speeds | 16/20 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 15 inch x 19-5/8 inch |
Table Size w/Extension Wings | 15 inch x 47-5/8 inch |
Table Height | 30-1/8 inch |
Cutterhead Diameter | 3 inch |
Cutterhead Speed | 5,000 RPM |
Number of Knives | 52 |
Number of Knives (helical) | 52 |
Table Support | 4-Column |
Motor | 3HP, 220V Only (1Ph, 12 Amp) |
Motor 1Ph | 3HP, 220V Only |
Overall Dimensions | 28 inch x 47-1/2 inch x 52 inch |
Net Weight | 401 lbs. |
Gross Weight | 470 lbs. |
20 inch Planer with Helical Cutterhead - 5HP, 1PH - M-4430
|
Specifications | |
---|---|
Model Number | 4430 |
Overall Dimension | 51 inch(L) x 40 inch(W) x 46-1/2 inch(H) |
Ph | 1Ph |
Stock No. (5HP, 1Ph) | 4430.201 |
Stock Number | M-4430 |
Maximum Stock Width | 20 inch |
Maximum Depth of Cut | 1/4 inch (Stock less than 8 inch wide) 1/8 inch(Full Width) |
Maximum Stock Thickness | 8 inch |
Minimum Stock Thickness | 1/4 inch |
Minimum Stock Length | 7 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 650 CFM |
Feed Speeds | 16/20 |
Bed Rollers | 1, Adjustable |
Table Size | 21 inch x 20 inch |
Table Size w/Extension Wings | 51 inch x 20 inch |
Table Height | 29-3/4 inch |
Cutterhead Diameter | 3-1/4 inch |
Cutterhead Speed | 3450 RPM |
Number of Knives | 68 |
Number of Knives (helical) | 68 |
Footprint | 22-1/2 inch (L) x 28-3/4 inch(W) |
Footprint - with Table | 51 inch(L) x 40 inch(W) x 46-1/2 inch(H) |
Motor | Included 10 Cutter inserts and compatible Torx screws. |
Motor 1Ph | 5HP 1Ph 230V (1Ph, 18 Amp) |
Overall Dimensions | 38-1/4 inch (L) x 32 inch(W) x 51-3/4 inch(H) |
Net Weight | 546 lbs. |
Gross Weight | 625 lbs. |
22 inch Planer with 4-Knife HSS Straight Cutterhead - 4455.001 - 7.5HP, 1PH
|
Specifications | |
---|---|
Model Number | 4455.001 |
CutterHead | 4 Knife HSS |
Ph | 1Ph |
Stock No. (7.5HP, 1Ph, Straight) | 4455.001 |
Stock Number | 0 |
Maximum Stock Width | 22 inch |
Maximum Stock Thickness | 9 inch |
Minimum Stock Thickness | 1/8 inch |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Outfeed Roller Diameter | 3-5/16 inch |
Feed Speeds | 20 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 23-3/4 inch x 32-1/4 inch |
Cutterhead Diameter | 3 inch |
Cutterhead Speed | 5,000 RPM |
Number of Knives (straight) | 4 |
Number of Knives Byrd | 110 Inserts |
Footprint | 44 inch L x 22 inch W |
Table Support | 2-Column |
Motor 1Ph | 7.5HP, 220V Only (38 Amp) |
Overall Dimensions | 45 inch W x 32 inch D x 50 inch H |
Net Weight | 1,340 lbs. |
Gross Weight | 1,550 lbs. |
22 inch Planer with 4-Knife HSS Straight Cutterhead - 4455.001 - 10HP, 3PH
|
Specifications | |
---|---|
Model Number | 4455.002 |
CutterHead | 4 Knife HSS |
Ph | 3Ph |
Stock No. (10HP, 3Ph, Straight) | 4455.002 |
Stock Number | 0 |
Maximum Stock Width | 22 inch |
Maximum Stock Thickness | 9 inch |
Minimum Stock Thickness | 1/8 inch |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Outfeed Roller Diameter | 3-5/16 inch |
Feed Speeds | 20 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 23-3/4 inch x 32-1/4 inch |
Cutterhead Diameter | 3 inch |
Cutterhead Speed | 5,000 RPM |
Number of Knives (straight) | 4 |
Number of Knives Byrd | 110 Inserts |
Footprint | 44 inch L x 22 inch W |
Table Support | 2-Column |
Motor 3Ph | 10HP, 240V/440V*, Prewired 220V (26/13 Amp) |
Overall Dimensions | 45 inch W x 32 inch D x 50 inch H |
Net Weight | 1,340 lbs. |
Gross Weight | 1,550 lbs. |
22 inch Planer with Byrd Shelix Cutterhead - 4455.103B - 7.5HP, 1PH
|
Specifications | |
---|---|
Model Number | 4455.103B |
CutterHead | Byrd Shelix |
Ph | 1Ph |
Stock No. (7.5HP, 1Ph, Byrd) | 4455.103B |
Stock Number | 0 |
Maximum Stock Width | 22 inch |
Maximum Stock Thickness | 9 inch |
Minimum Stock Thickness | 1/8 inch |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Outfeed Roller Diameter | 3-5/16 inch |
Feed Speeds | 20 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 23-3/4 inch x 32-1/4 inch |
Cutterhead Diameter | 3 inch |
Cutterhead Speed | 5,000 RPM |
Number of Knives (straight) | 4 |
Number of Knives Byrd | 110 Inserts |
Footprint | 44 inch L x 22 inch W |
Table Support | 2-Column |
Motor 1Ph | 7.5HP, 220V Only (38 Amp) |
Overall Dimensions | 45 inch W x 32 inch D x 50 inch H |
Net Weight | 1,340 lbs |
Gross Weight | 1,550 lbs. |
22 inch Planer with Byrd Shelix Cutterhead - 4455.104B - 10HP, 3PH
|
Specifications | |
---|---|
Model Number | 4455.104B |
CutterHead | Byrd Shelix |
Ph | 3Ph |
Stock No. (7.5HP, 1Ph, Byrd) | 4455.104B |
Stock Number | 0 |
Maximum Stock Width | 22 inch |
Maximum Stock Thickness | 9 inch |
Minimum Stock Thickness | 1/8 inch |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Outfeed Roller Diameter | 3-5/16 inch |
Feed Speeds | 20 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 23-3/4 inch x 32-1/4 inch |
Cutterhead Diameter | 3 inch |
Cutterhead Speed | 5,000 RPM |
Number of Knives (straight) | 4 |
Number of Knives Byrd | 110 Inserts |
Footprint | 44 inch L x 22 inch W |
Table Support | 2-Column |
Motor 3Ph | 10HP, 240V/440V*, Prewired 220V (26/13 Amp) |
Overall Dimensions | 45 inch W x 32 inch D x 50 inch H |
Net Weight | 1,340 lbs |
Gross Weight | 1,550 lbs. |
25 inch Planer with 4-Knife HSS Straight Cutterhead - 4470.001 - 10HP, 1PH
|
Specifications | |
---|---|
Model Number | 4470.001 |
CutterHead | 4 Knife HSS |
Stock No. (10HP, 1Ph, Straight) | 4470.001 |
Stock Number | 0 |
Maximum Stock Width | 25 inch |
Maximum Depth of Cut | 1/4 inch for 0 inch – 11-3/4 inch and 1/8 inch for 11-3/4 inch – 25 inch |
Maximum Stock Thickness | 9-1/4 inch |
Minimum Stock Thickness | 1/8 inch Manual, 15/64 inch Automatic |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Steel Outfeed Roller Diameter | 3 inch (x2) |
Feed Speeds | 20, 25 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 26 inch x 32 inch |
Cutterhead Diameter | 3-3/8 inch |
Cutterhead Speed | 4,800 RPM |
Number of Knives (straight) | 4 |
Footprint | 47-1/2 inch L x 21 inch W |
Table Support | 2-Column |
Motor 1Ph | 10HP, 240V Only (43 Amp) |
Overall Dimensions | 46 inchL x 23 inchW x 56 inchH |
Net Weight | 1,732 lbs. |
Gross Weight | 1,850 lbs. |
25 inch Planer with 4-Knife HSS Straight Cutterhead - 4470.002 - 15HP, 3PH
|
Specifications | |
---|---|
Model Number | 4470.002 |
CutterHead | 4 Knife HSS |
Ph | 3Ph |
Stock No. (15HP, 3Ph, Straight) | 4470.002 |
Stock Number | 0 |
Maximum Stock Width | 25 inch |
Maximum Depth of Cut | 1/4 inch for 0 inch – 11-3/4 inch and 1/8 inch for 11-3/4 inch – 25 inch |
Maximum Stock Thickness | 9-1/4 inch |
Minimum Stock Thickness | 1/8 inch Manual, 15/64 inch Automatic |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Steel Outfeed Roller Diameter | 3 inch (x2) |
Feed Speeds | 20, 25 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 26 inch x 32 inch |
Cutterhead Diameter | 3-3/8 inch |
Cutterhead Speed | 4,800 RPM |
Number of Knives (straight) | 4 |
Footprint | 47-1/2 inch L x 21 inch W |
Table Support | 2-Column |
Motor 3Ph | 15HP, 240V/440V* Prewired 220V (37 Amps) |
Overall Dimensions | 46 inchL x 23 inchW x 56 inchH |
Net Weight | 1,732 lbs. |
Gross Weight | 1,850 lbs. |
25 inch Planer with Byrd Shelix Cutterhead - 4470.101B - 10HP, 1PH
|
Specifications | |
---|---|
Model Number | 4470.101B |
CutterHead | Byrd Shelix |
Ph | 1Ph |
Stock No. (10HP, 1Ph, Byrd) | 4470.101B |
Stock Number | 4470B |
Maximum Stock Width | 25 inch |
Maximum Depth of Cut | 1/4 inch for 0 inch – 11-3/4 inch and 1/8 inch for 11-3/4 inch – 25 inch |
Maximum Stock Thickness | 9-1/4 inch |
Minimum Stock Thickness | 1/8 inch Manual 15/64 inch Automatic |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Steel Outfeed Roller Diameter | 3 inch (x2) |
Feed Speeds | 20, 25 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 26 inch x 32 inch |
Cutterhead Diameter | 3-3/8 inch |
Cutterhead Speed | 4,800 RPM |
Number of Knives Byrd | 125 |
Footprint | 47-1/2 inch L x 21 inch W |
Table Support | 2-Column |
Motor 1Ph | 10HP, 240V Only (43 Amps) |
Overall Dimensions | 46 inchL x 23 inchW x 56 inchH |
Net Weight | 1,732 lbs. |
Gross Weight | 1,850 lbs |
25 inch Planer with Byrd Shelix Cutterhead - 4470.102B - 15HP, 3PH
|
Specifications | |
---|---|
Model Number | 4470.102B |
CutterHead | Byrd Shelix |
Ph | 3Ph |
Stock No. (15HP, 3Ph, Byrd) | 4470.102B |
Stock Number | 4470B |
Maximum Stock Width | 25 inch |
Maximum Depth of Cut | 1/4 inch for 0 inch – 11-3/4 inch and 1/8 inch for 11-3/4 inch – 25 inch |
Maximum Stock Thickness | 9-1/4 inch |
Minimum Stock Thickness | 1/8 inch Manual 15/64 inch Automatic |
Minimum Stock Length | 10 inch |
Dust Port Diameter | 5 inch |
Minimum CFM Required | 900 CFM |
Infeed Roller Diameter | 3 inch |
Steel Outfeed Roller Diameter | 3 inch (x2) |
Feed Speeds | 20, 25 and 30 FPM |
Bed Rollers | 2, Adjustable |
Table Size | 26 inch x 32 inch |
Cutterhead Diameter | 3-3/8 inch |
Cutterhead Speed | 4,800 RPM |
Number of Knives Byrd | 125 |
Footprint | 47-1/2 inch L x 21 inch W |
Table Support | 2-Column |
Motor 3Ph | 15HP, 240V/440V* Prewired 220V (38/19 Amps) |
Overall Dimensions | 46 inchL x 23 inchW x 56 inchH |
Net Weight | 1,732 lbs. |
Gross Weight | 1,850 lbs |
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM
SOUTHERN TOOL SPECIAL = FREE SHIPPING, RESIDENTIAL AND/OR LIFTGATE EXTRA
SOUTHERN TOOL SPECIAL = FREE SHIPPING, RESIDENTIAL AND/OR LIFTGATE EXTRA
SOUTHERN TOOL SPECIAL = FREE SHIPPING, RESIDENTIAL AND/OR LIFTGATE EXTRA
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM, ALSO FREE SHIPPING - RESIDENTIAL AND/OR LIFTGATE EXTRA
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM, ALSO FREE SHIPPING - RESIDENTIAL AND/OR LIFTGATE EXTRA
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM, ALSO FREE SHIPPING - RESIDENTIAL AND/OR LIFTGATE EXTRA
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM, ALSO FREE SHIPPING - RESIDENTIAL AND/OR LIFTGATE EXTRA
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM, ALSO FREE SHIPPING - RESIDENTIAL AND/OR LIFTGATE EXTRA
ADD TO CART OR CALL 800-458-3687 X1 FOR YOUR EXCLUSIVE BROTHER-IN-LAW PRICE ON THIS OLIVER ITEM, ALSO FREE SHIPPING - RESIDENTIAL AND/OR LIFTGATE EXTRA
