Edwards Shop Equipment

Call For the Best - Brother In Law - Delivered Price
on Edwards Ironworkers and Accessories
Ask about our Accessory Deals



Shop Presses	Pipe / Tube Bender	Portable Power Unit

Horizontal Press	Radius Roller	14-inch Combination Support Stand

shop presses
Pipe / Tube Bender
Portable Power Unit
horizontal press
radius roller
combo support stand

20 Ton Compact and Powerful Benchtop Press

20 Ton Shop Press

Heavy-Duty 3/8 inch Steel Construction
Cylinder with 2 inch Ram and 6-1/4 inch Stroke
Rolling Cylinder for Maximum Versatility
Working Area of 10-1/2 x 20 inch
Easy-to-Use Hand/Jog Controls
Quick Disconnect Hoses
Hydraulic-Assist Table Height Adjustment

Our 20 Ton Shop Press may be small but its no lightweight. Smooth and precise, heavy-duty and versatile, the unique open side design allows for material to pass through. Power it up with an Edwards Ironworker with factory installed Hydraulic Accessory Pack or an Edwards Porta Power 5HP, 2750 psi portable power unit.

Check out our 12 inch Press Brake Tooling, bump-die tooling, the 6-Piece Press Tooling Set and the Press Brake Back Gauge.

40 Ton Full Size at Half the Price

40 ton press

Heavy-Duty 1/2 inch Steel Construction
Cylinder with 4 inch Ram and 12-1/4 inch Stroke
Rolling Cylinder for Maximum Versatility
Working Area of 38 x 40-1/2 inch
Easy-to-Use Hand/Jog Controls
Quick-Disconnect Hoses
Hydraulic-Assist Table Height Adjustment

Our full-sized 40 Ton Shop Press is rugged and economical. Smooth and precise, heavy-duty and versatile, the unique open side design allows for material to pass through. Power it up with an Edwards Ironworker with factory installed Hydraulic Accessory Pack or an Edwards Porta Power 5HP, 2750psi portable power unit.

With the Press Brake Tooling, your Shop Press easily becomes a brake. Check out our bump-die tooling, the 6-Piece Press Tooling Set and the Press Brake Back Gauge.

60 Ton Shop Press

Press the Limit

1/2 inch and 3/4 inch Heavy-Duty Steel Construction
Easy-to-Use Foot Pedal
Versatile Rolling Cylinder
Working Area of 42 inch x 39 inch
Pressure Gauge
Quick-Disconnect Hoses
Hydraulic-Assist Table Height Adjustment
2 V-Blocks Included

Our 60 Ton Shop Press solves a variety of demands to improve users productivity. Smooth and precise, heavy-duty and versatile, our unique, open side design allows for material to pass through. Power it up with an Edwards Ironworker with factory installed Hydraulic Accessory Pack or an Edwards Porta Power 5 HP, 3000 PSI portable power unit. Also available with PLC (Programmable Logic Control) to further increase efficiency.

Improve your productivity with PLC on repeatable actions. Provides adjustable up/down stroke control saving time. Adjustable PSI allows the user to set the pressure and cycle the press with an automatic return. Magnetic base allows easy mounting of the PLC anywhere on the machine.

With the Press Brake Tooling, your Shop Press easily becomes a brake. Check out our bump-die tooling, the 6-Piece Press Tooling Set and the Press Brake Back Gauge.

60 Ton Shop Press General Specifications Edwards Ironworker / Porta-Power
Standard Motor	5 HP 3ph 208 V or 230 V 1725 RPM 14 A
Optional Motors	5 HP 3ph 460 V 1725 RPM 7 A 5 HP 1ph 230 V 1725 RPM 23 A
Hydraulic Pump	3-1/2 GPM - 1 Stage
Valve Pressure	2750 PSI
Reservoir	7 Gallons
Rating	60 Tons
Cylinder	4 inch Ram
Stroke	12-1/4 inch
Height	84.3 inch
Width	54 inch
Depth	48 inch
Shipping Weight	1,874 lb

110 Ton Shop Press

Our Most Powerful Press

Heavy-Duty 3/4 inch Steel Construction
Easy-to-Use Foot/Jog Controls
Versatile Rolling Cylinder
Working Area of 48 inch x 37-1/2 inch
Pressure Gauge
Quick-Disconnect Hoses
Hydraulic-Assist Table Height Adjustment
2 V-Blocks Included

Our 110 Ton Shop Press has the capacity to meet your shops needs. Smooth and precise, heavy-duty and versatile, our unique, open side design allows for material to pass through. Power it up with an Edwards Ironworker with factory installed Hydraulic Accessory Pack or an Edwards Porta Power 5 HP, 3000 PSI portable power unit. Also available with PLC (Programmable Logic Control) to further increase efficiency.

Improve your productivity with PLC on repeatable actions. Provides adjustable up/down stroke control saving time. Adjustable PSI allows the user to set the pressure and cycle the press with an automatic return. Magnetic base allows easy mounting of the PLC anywhere on the machine.

With the Press Brake Tooling, your Shop Press easily becomes a brake. Check out our bump-die tooling, the 6-Piece Press Tooling Set and the Press Brake Back Gauge.

110 Ton Shop Press General Specifications Edwards Ironworker / Porta-Power
Standard Motor	5 HP 3~ 208 V or 230 V 1725 RPM 14 A
Optional Motors	5 HP 3~ 460 V 1725 RPM 7 A 5 HP 1~ 230 V 1725 RPM 23 A
Hydraulic Pump	3-1/2 GPM - 1 Stage
Valve Pressure	2750 PSI
Reservoir	7 Gallons
Rating	110 Tons
Cylinder	4 inch Ram
Stroke	12-1/4 inch
Height	85.4 inch
Width	64 inch
Depth	48 inch
Shipping Weight	2,690 lb

brake

Press Brake Tooling - Turn your press into a brake!

Press Brake tooling is designed for both our 20 Ton and 40 Ton Shop Presses. With clear operating widths of 12, 18, 24 or 32 inches the Press Brake Tooling features our milled, heavy-duty punch and 4-way die block. The robust tooling is mounted to a machined solid steel base and pushblock. Heavy duty springs return the bump brake to its neutral position.

Press Brake Tooling Set - Press a little here, a little there.

The 6 piece tooling set includes tapered and cutaway push blocks. Installs simply with a ball detent screw to the ram of either the 20 or 40 Ton Shop Press.

Press Brake Back Gauge - Make repeatable bends

Our adjustable Press Brake Back Gauge makes for easy set-up of repeatable bends. Simply bolt it up to the Edwards Ironworker Brake Tooling assembly or Press Brake Tooling for our 20 Ton Shop Press and 40 Ton Shop Press, and a simple hand crank glides the carriage backstop to your desired brake location.

20 ton and 40 ton shop presses, brakes and accessories
HAT2000	20 Ton Shop Press (Requires Hydraulic Pump)
HAT4000	40 Ton Shop Press (Requires Hydraulic Pump)
HAT8000	NEW - 60 Ton Shop Press
HAT8050	NEW - 60 Ton Shop Press with PLC
HAT8020	NEW - 60 Ton Shop Press and Porta Power 3 Phase, 230 Volt
HAT8070	NEW - 60 Ton Shop Press with PLC and Porta Power 3 Phase, 230 Volt
HAT8030	NEW - 60 Ton Shop Press and Porta Power 3 Phase, 460 Volt
HAT8080	NEW - 60 Ton Shop Press with PLC and Porta Power 3 Phase, 460 Volt
HAT8010	NEW - 60 Ton Shop Press and Porta Power 1 Phase, 230 Volt
HAT8060	NEW - 60 Ton Shop Press with PLC and Porta Power 1 Phase, 230 Volt
HAT9000	NEW - 110 Ton Shop Press
HAT9050	NEW - 110 Ton Shop Press with PLC
HAT9020	NEW - 110 Ton Shop Press and Porta Power 3 Phase, 230 Volt
HAT9070	NEW - 110 Ton Shop Press with PLC and Porta Power 3 Phase, 230 Volt
HAT9080	NEW - 110 Ton Shop Press with PLC and Porta Power 3 Phase, 460 Volt
HAT9030	NEW - 110 Ton Shop Press and Porta Power 3 Phase, 460 Volt
HAT9010	NEW - 110 Ton Shop Press and Porta Power 1 Phase, 230 Volt
HAT9060	NEW - 110 Ton Shop Press with PLC and Porta Power 1 Phase, 230 Volt
PRB12	12 inch Shop Press (To be used with Edwards 20 Ton or 40 Ton Shop Press)
PRB18	18 inch Shop Press (To be used with Edwards 20 Ton or 40 Ton Shop Press Requires Hydraulic Pump)
PRB24	24 inch Press Brake (To be used with Edwards 20 Ton or 40 Ton Shop Press Requires Hydraulic Pump)
PRB32	32 inch Press Brake (To be used with Edwards 20 Ton or 40 Ton Shop Press Requires Hydraulic Pump)


10 Ton Tube/Pipe Hydraulic Bender	Tube and Pipe Dies

10 Ton Tube/Pipe Bender

Powered by the 40Ton (A) through 120Ton (A) Ironworker models, Elite Ironworker Series or our Porta Power, the 10 Ton Tube / Pipe Bender is a quick-connect hydraulic tool that expands your shop without breaking the bank. The Edwards 10Ton Tube / Pipe Bender powers through 2 in ID SCH40 pipe, 2.5 in O.D. tube and 2 in square tube fast and accurately. Features hand-jog operation, auto-stop controls for repeatability and a heavy duty rolling frame with rotating yoke for both horizontal and vertical bending operations.

Our 10 Ton Bender is a quick-connect hydraulic tool to greatly expand your fabrication capabilities. Designed for medium to heavy material

Get Bent!

Plug + Play Operation
Horizontal or Vertical Operating Positions
Proximity Switch Allows Easy, Repeatable Bends
Heavy-Duty Rolling Stand
Easy-to-Use Hand/Jog Controls

Our 10 Ton Bender is a quick-connect hydraulic tool to greatly expand your fabrication capabilities. Designed for medium to heavy material, the Edwards 10 Ton Bender powers through 2 inch (I.D.) Schedule 40 pipe, 2-1/2 inch (O.D.) tube and 2 inch square tube quickly and accurately. Choose from our over 260 standard Bender Die Sets to get your job done. Call for custom die information and material compatibility requirements.

See links Below for Bender dies pricing page	See below to download dies pdf
Click here for pricing on Round Tube Dies Click here for pricing on Round Pipe Dies Click here for pricing on Square Dies	Click to download Tube Dies pdf Click to download Pipe Dies pdf Click to download Square Dies pdf

Power it up with an Edwards Ironworker with factory installed Hydraulic Accessory Pack or an Edwards Porta Power 5hp, 2750psi, portable power unit.

General Specifications:

Heavy Duly All Steel Construction
Smooth, Fast operation
180 Degree Bend Capacity
Easy To Use Hand Controls
Operates Horizontal or Vertically
Heavy Duty Rolling and Locking Stand
Auto Stop Feature For Repeatable Bends
Quick Disconnect Hoses
2in (10) Schedule 40 Pipe Capacity
2-1/2in (00) .095in Tube Capacity
2-1/4in .083in Chromoly Capacity
Die Sets Sold Separately
One Year Warranty
Cylinder 1-3/4in ram
Stroke 14in

Edwards 10 Ton Stand Alone Pipe and Tube Bender
HAT1000	10 Ton Tube/Pipe Bender (Requires Hydraulic Pump Installed on the IW at time of Order OR Stand Alone Hydraulic Pump)
HAT1010	10 Ton Bender and Porta Power 1 Phase, 230 Volt
HAT1020	10 Ton Bender and Porta Power 3 Phase, 230 Volt

Precise and Durable

Our Edwards Bender Dies work solid round, solid square, Schedule 40 pipe, round and square tube. Dies and wipers are precision machined to ensure the highest quality bends. Choose from our over 260 standard Bender Die Sets to get your job done. Call for custom die information and material compatibility requirements.

Die sets
Die sets include: Forming Die Saddle Strap Saddle Bolt Degree Pointer Fine Adjustment Bolt Wiper Mounting Block Brass Wiper Blades (2) Wiper Mounting Bolts (2) Adjustment Set-Screw

Die sets

Die sets include:

Forming Die
Saddle Strap
Saddle Bolt
Degree Pointer
Fine Adjustment Bolt
Wiper Mounting Block
Brass Wiper Blades (2)
Wiper Mounting Bolts (2)
Adjustment Set-Screw

GENERAL SPECIFICATIONS EDWARDS IRONWORKER/ PORTA-POWER
Standard Motor	5 HP 3~ 208 V or 230 V 1725 RPM 14 A
Optional Motors	5 HP 3~ 460 V 1725 RPM 7 A 5 HP 3~ 575 V 1725 RPM 6 A 5 HP 1~ 208 V or 230 V 1725 RPM 23 A
Hydraulic Pump	3-1/2 GPM - 1 Stage
Valve Pressure	2750 PSI
Reservoir	7 Gallons
Bend Capacity	180 degree
Pipe Capacity	2 inch (ID) Schedule 40
Tube Capacity	2-1/2 inch (OD) .095 inch
Square Tube Capacity	2 inch (OD) .25 inch
Chromoly Capacity	2-1/4 inch (OD) .083 inch
Cylinder	1-3/4 inch Ram
Stroke	14 inch
Height	40-1/2 inch
Width	36-1/2 inch
Depth	42 inch
Shipping Weight	600 lb

THE EDWARDS PORTABLE POWER UNIT IS AN ADDITIONAL POWER SOURCE FOR YOUR EDWARDS POWERLINK HYDRAULIC TOOLS. THE PORTABLE POWER UNIT IS COMPACT, MOBILE, AND IS SET UP TO ACCOMMODATE ALL OF EDWARDSâ QUICK-CONNECT HYDRAULIC ACCESSORY TOOLS AND NOW AVAILABLE OPERATING USING 1PH/120V POWER!

Simply PLUG IN and POWER UP any of our Hydraulic Tools and expand your fabrication capabilities
Designed to be a stand alone power source for the Edwards Hydraulic Tools, the Portable Power Unit is also a great complimentary option to your Ironworker when your projects demand multiple Hydraulic Tools.

FLEXIBILITY

Mobile PowerLink System is a power source to operate all Edwards Hydraulic Tools

PRODUCTIVITY

Heavy-duty castors provide easy portability to move around your shop
Quick connect couplings are easy to use allowing rapid transitions between Edwards Hydraulic Tools

SAFETY

Integrated Lock-out/Tag-out system with E-Stop for added safety

For use on Edwards:

10 Ton Tube and Pipe Benders
20 Ton Hydraulic Shop Press
40 Ton Hydraulic Shop Press

Specifications Porta Power unit
STOCK #	HAT007	HAT001	HAT002	HAT003	HAT004	HAT005	HAT006
DESCRIPTION	1 Phase, 120V	1 Phase, 230 V	3 Phase, 230 V	3 Phase, 380 V	3 Phase, 460 V	3 Phase, 575 V	3 Phase, 208 V
MOTOR (HP)	2	5	5	5	5	5	5
AMPS	17	23	14	9.5	7	6	14
RPM	3600	1725	1725	1725	1725	1725	1725
HYDRAULICS (GPM)	5/2 Two-Stage	3-1/2	3-1/2	3-1/2	3-1/2	3-1/2	3-1/2
HYDRAULICS (PSI)	2850	3000	3000	3000	3000	3000	3000
RESERVOIR (GAL)	7	7	7	7	7	7	7
PRODUCT DIM (IN)	15-1/4 x 37-1/2 x 31-1/4	15-1/4 x 37-1/2 x 31-1/4	15-1/4 x 37-1/2 x 31-1/4	15-1/4 x 37-1/2 x 31-1/4	15-1/4 x 37-1/2 x 31-1/4	15-1/4 x 37-1/2 x 31-1/4	15-1/4 x 37-1/2 x 31-1/4
SHIPPING DIM (IN)	24 x 48 x 37	24 x 48 x 37	24 x 48 x 37	24 x 48 x 37	24 x 48 x 37	24 x 48 x 37	24 x 48 x 37
PRODUCT WEIGHT (LBS.)	392	392	392	392	392	392	392
SHIPPING WEIGHT (LBS.)	400	400	400	400	400	400	400
COUNTRY OF MAN	USA	USA	USA	USA	USA	USA	USA
Warranty	1 Year Parts	1 Year Parts	1 Year Parts	1 Year Parts	1 Year Parts	1 Year Parts	1 Year Parts

10 Ton Portable Hydraulic Power Unit
HAT001	1 Phase, 230 V
HAT002	3 Phase, 230 V
HAT003	3 Phase, 380 V
HAT004	3 Phase, 460 V
HAT005	3 Phase, 575 V
HAT006	3 Phase, 208 V

Hydraulic Accessory Pack

Transform your Edwards Ironworker into a one-stop fab shop!

This Factory installed Option allows you to quickly connect and power our 10 Ton Bender as well as our 20 Ton and 40 Ton shop presses. An extraordinary way to grow your capabilities without expanding your shop floor or breaking your bank.

Factory Installed Hydraulic Pumos - New Machines ONLY!
AC400	AC400 - Factory Installed Hydraulic Accessory Pack Available on new machines only 40 Ton Model Only.
AC500	AC500 - Factory Installed Hydraulic Accessory Pack Available on new machines only 50, 55 and 60 Ton Models Only.
AC600	AC600 - Factory Installed Hydraulic Accessory Pack Available on new machines only 3 phase, 65, 75 and 100 Ton ModelS Only. (NOT FOR 100 TON DELUXE MODEL)
AC700	AC700 - Factory Installed Hydraulic Accessory Pack Available on new machines only 1 phase 65, 75 and 100 Ton ModelS Only. (NOT FOR 100 TON DELUXE MODEL)
AC800	AC800 - Factory Installed Hydraulic Accessory Pack Available on new machines only 100 Ton Deluxe Model Only.
AC900	AC900 - Factory Installed Hydraulic Accessory Pack Available on new machines only 120 Ton Model Only.

ELITE Model have Factory Installed Hydraulic Pumps Installed as Standard Equipment

edwards horizontal press

Your Go-To Tool

With 20 tons of force, the Edwards Horizontal Press accepts a great variety of tooling to form, brake, and straighten mild steel. This compact powerhouse quickly connects to your Edwards Ironworker with a Hydraulic Accessory Pack or Edwards Porta-Power to greatly expand your fabrication capabilities. Designed for maximum tooling flexibility, the 4 pin locations are locked with a simple crank for inboard tool squaring. The included digital encoder reads positive stop for accurate repeatability within 0.01 inch. The potential of this tool is only limited by your imagination

Features:

20 Tons of Power
Digital Readout
Hardened Tooling Pins
4 Pin Locations for Tooling Flexibility
Smooth Ram Extensions
Robust Construction
2 Inch Machine Heavy Duty Table
Machined Hardened Bushings

Included Tooling : 6 Inch Brake 4 Way Die

The 4 way Brake Set comes standard with the HP20T Horizontal Press. Designed for maximum versatility, the 4 way brake set includes a 6 inch brake holder and a 6 inch punch arbor that allows for braking projects up to 1/2 inch thick x 6 inches tall. The 4 way brake set is easily configured to create clips, brakets, hangers, angles and box geometires quickly and easily.

Specifications Horizontal Press
Standard Motor	5 HP 3~ 208 V or 230 V 1725 RPM 14 A
Optional Motors	5 HP 3~ 460 V 1725 RPM 7 A 5 HP 3~ 575 V 1725 RPM 6 A 5 HP 1~ 230 V 1725 RPM 23 A
	Standard	Metric
Hydraulic Pump	3-1/2 GPM - 1 Stage	13.3 LPM - 1 Stage
Valve Pressure	2750 PSI	18960.6 kPa
Reservoir	7 Gallons	26.5 Liters
GENERAL SPECIFICATIONS
Rating	20 Tons
Cylinder	2.25 inch Ram	57.15mm Ram
Stroke	10 inch	254mm
Work Height	38 - 40 inch	965.2mm-1016mm
Table Dimensions	24 x 42 inch	609.6mm x 1066.8mm
Weight	1350 lb	612.35 kg
TOOLING DETAILS
Pin Diameter	2 inch	50.8mm
Dimensions	9.79 inch min to 13.54 inch max (tool chuck to pin centers)	248.66mm min to 343.91mm max (tool chuck to pin centers)
Pin Height	6 inch max (standard tooling)	152.4mm max (standard tooling)
Tooling Head	1/2 inch T Nut/Set Screw and American Standard Brake Punch Tooling	12.7mm T Nut/Set Screw and American Standard Brake Punch Tooling

Horizontal Press
HAT6000	Horizontal Press
Horizontal Press Bundle
HAT6010	Horizontal Press and Porta Power 1 Phase, 230 Volt
HAT6020	Horizontal Press and Porta Power 3 Phase, 230 Volt
HAT6030	Horizontal Press and Porta Power 3 Phase, 460 Volt

Edwards Radius Roller

Just Roll With It!

Our Pipe, Tube and Section Radius Roller is another essential quick-connect hydraulic tool. Plug it into your Edwards Ironworker with the Hydraulic Accessory Pack or power it separately with an Edwards Porta-Power to greatly expand your fabrication capabilities. Designed for medium to heavy material, the Edwards Radius Roller powers through your job quickly and accurately. The variable speed hydraulic drive allows you to dial in the appropriate speed for various materials. Quickly change the orientation from vertical for smaller projects to horizontal for those larger, heavier jobs.

Features:

Variable Speed
Single Pinch / Dual Drive
Plug and Play Operation
Easy to Use Hand / Jog Controls
Horizontal or Vertical Operation
Easy Repeatable Rolls
Heavy duty Portable Stand
Pinch Roll Scales and Lateral Roll Guides

GENERAL SPECIFICATIONS EDWARDS IRONWORKER/ PORTA-POWER
Standard Motor	5 HP 3~ 208 V or 230 V 1725 RPM 14 A
Optional Motors	5 HP 3~ 460 V 1725 RPM 7 A 5 HP 3~ 575 V 1725 RPM 6 A 5 HP 1~ 230 V 1725 RPM 23 A
	Standard	Metric
Hydraulic Pump	3-1/2 GPM - 1 Stage	13.3 LPM - 1 Stage
Valve Pressure	2750 PSI	18960.6 kPa
Reservoir	7 Gallons	26.5 Liters
DIMENSIONS
Height	43 inch	1092.2mm
Width	49 inch	1244.6mm
Depth	49 inch	1244.6mm
GENERAL SPECIFICATIONS
Shaft Diameter	2.0 inch	50.8mm
Shaft Center Distance	14.12 inch	358.6mm
MATERIAL CAPACITIES
Round Pipe	2 inch Schedule 40	50.8mm Schedule 40
Round Tube	2-1/2 inch (.095 inch)	63.5mm (2.41mm)
Square Tube	2 inch (.120 inch)	50.8mm (3.04mm)
Solid Round	1.375 inch	34.92mm
Flat Bar - Easy Way	3 inch (.375 inch)	76.2(19.05mm)
Flat Bar - Hard Way	2.25 inch (.375 inch)	57.15(9.52mm)
Angle Iron	2 inch (.250 inch)	50.8mm(6.35mm)

Radius Roller
HAT5000	Radius Roller
Radius Roller Bundle
HAT5010	Radius Roller and Porta Power 1 Phase, 230 Volt
HAT5020	Radius Roller and Porta Power 3 Phase, 230 Volt
HAT5030	Radius Roller and Porta Power 3 Phase, 460 Volt

15 piece die set for edwards radius roller

The Universal Die Set comes standard with the RPM2. Designed for maximum versatility, the Universal Die Set is easily configured to accept a wide variety of metal sections. Get rollin and work your flats, angle, channel, and square tube with this versatile 15 piece set.

* Special order round tube and pipe dies avaliable upon request

EDWARDS 14" COMBINATION HORIZONTAL & V-MATERIAL SUPPORT STAND

EDWARDS 14 inch COMBINATION HORIZONTAL and V-MATERIAL SUPPORT STAND

T Flat Mode

EDWARDS 14 inch COMBINATION HORIZONTAL and V-MATERIAL SUPPORT STAND

V-Material Mode

EDWARDS 14 inch COMBINATION HORIZONTAL and V-MATERIAL SUPPORT STAND

OVERVIEW

Originally designed for use with Edwards products, we quickly realized that this heavy duty roller stand would be a welcome addition to any shop, no matter what brand was being used. This roller stand provides support for up to 500 lbs of material in many different configurations.

FEATURES and BENEFITS

Operates in multiple configurations to be compatible with a variety of materials and machines.

Can be used in either a flat T configuration or a V configuration.
Accepts a wide variety of materials including flat bar, angle iron, solid rod, tube and pipe or whatever else you are using.
Smooth steel rollers for easy movement
500 lbs capacity
Fast and easy adjustments for height and roller angle.

T POSITION FOR FLAT MATERIAL SUPPORT

Height adjusts in T layout from 30.8 to 49.9 inch
Width or rollers in T layout is 14 inch

V POSITION FOR ANGLE IRON OR SOLID ROD SUPPORT

Height adjusts in V layout from 31.8 to 51.1 inch
V arm length is 4.5 inch

SPECIFICATIONS
Model Number	AC1980
Weight Max Capacity (lbs.)	500
Height Adjustment Range - T Layout Flat (in.)	30.8 - 49.9
Height Adjustment Range - V Layout (in.)	31.8 - 51.1
Roller Die Width (in.)	8
Roller Die Diameter (in.)	1.9
Product Dimensions (in.)	18.5 x 22.1 x 31.8
Shipping Dimensions	30 x 26 x 7
Product Weight (lbs.) 50 Shipping Weight (lbs.)	55

Edwards 14-inch Combination Support Stand
AC1980	Edwards 14-inch Combination Support Stand
