Heck Pneumatic Bevel-Mills


Heck Bevel Mill and Plate Bevelers Logo

s-h alt



heck - bevel mill model 3000

Pneumatic Operation

heck - 5/16" & 3/4" bevel mill models 4000 & 5000 heck - 1-3/16" plate mill model 9000
Heck 3000 Model 4000 and 5000 Model 7000 and 8000 Model 9000
  3000 4000 5000 7000 8000 9000
Maximum Bevel (B) (in) 3/16 3/4 5/16 3/8 7/8 1-3/16
Min. Bevel 0 0 0 0 0 0
Min work piece thickness (in) 1/8 1/8 1/8 1/8 1/8 1/8
Bevel angle (deg) 15 - 45 15 - 45 15 - 45 15 - 45 15 - 45 15 - 45
V-Block Length 8" 8" 8" 8" 8" 9"
Weight 14 pounds 19 pounds 22 pounds 26 pounds 36 pounds 50 pounds
Number of inserts 5 5 10 5 10 10
Power pneumatic 4 hp
110 volt 		  2 hp
110 volt 		1/2 hp
110 volt 		1 hp
110 volt 		1 1/2 hp 110 volt
Radius inserts for corner rounding No Yes No Yes Yes No

Ideal for weld preparation

Our patented line of Beveling machines provide a more effective method of beveling over slow grinding and torch cutting.

No Vibration - No Heat - No Fumes - No Dust

Our milling cutters use standard square carbide inserts

  • Clean burr - free edges

  • Adjustable depth of cut

  • Variable angle 15 DEG - 45 DEG



  • Specials available for 60 DEGREE beveling

  • Easy to operate

  • Self supporting on the work piece

  • Pipe Beveling attachment included

Bevel-Mill Plate Beveler

Ideal for weld preparation

Our patented line of Beveling machines provide a more effective method of beveling over slow grinding and torch cutting. No Vibration - No Heat - No Fumes - No Dust

Our milling cutters use standard square carbide inserts

  • Clean burr - free edges
  • Adjustable depth of cut
  • Variable angle 15  - 45 degree
  • Specials available for 60 - 90 degree beveling
  • Easy to operate
  • Self supporting on the work piece
  • Pipe Beveling attachment included

Heck Pneumatic Bevel-Mill Model 3000

Heck Pneumatic Bevel-Mill Model 3000
Features

  • Pneumatic
  • Light Weight
  • Faster Chamfers
  • Trigger On-Off
  • Gear Drive
  • 3/16 inch Chamfers At 8ft Per Minute
  • Ideal For Light Beveling and Heavy Deburring
  • Clean-up Burn Out Parts Fast
  • Mold Bases
  • Die Blocks
MODEL 3000 BEVEL MILL SPECS
MINIMUM WORK PIECE THICKNESS 1/8 inch (3MM)
MINIMUM BEVEL 0
MAXIMUM BEVEL DEPTH 3/16 inch
BEVEL ANGLE 15 - 45 degree
V-BLOCK LENGTH 8 inch
NUMBER OF INSERTS 5
WEIGHT 14 POUNDS
Heck 3000 Bevel Mill
3000 MODEL 3000 BEVEL MILL - PNEUMATIC BEVELER, 3/16" DEPTH CUT
410 Replacement carbide insert C-5 grade
410-TCN Titanium coated carbide insert
WS410 Weld Shaver Insert



Heck Bevel-Mill Model 4000-5000

Heck Bevel-Mill Model 4000-5000

Features:

  • Double Insulated
  • Adjustable handle positions for comfortable operation
  • Trigger operation with lock
  • Specially designed gear drive motors
  • Variable speed control (optional)
SPECIFICATIONS
Bevel-Mill Model 4000 Model 5000
Minimum Work Piece Thickness 1/8 inch - 3mm 1/8 inch - 3mm
Minimum Bevel 0 0
Maximum Bevel (B) 3/4 inch - 19mm 5/16 inch - 8mm
Bevel Angle 15 - 45 15 - 45
V-Block Length 8 3/4 inch - 219mm 8 inch - 200mm
Number Of Inserts 10 5
Motor 4hp, 110V, 50/60hz 2hp, 110V, 50/60hz
Weight 22lbs - 10kg 19lbs - 8.6kg
Heck 5000 & 4000 Bevel Mills
5000 MODEL 4000 BEVEL MILL - 2 HP, 110 V, 5/16"  DEPTH CUT
4000 MODEL 4000 BEVEL MILL - 4 HP, 110 V, 3/4"  DEPTH CUT
410 Replacement carbide insert C-5 grade
410-TCN Titanium coated carbide insert



Heck Bevel-Mill Model 7000-8000

Heck Bevel-Mill Model 7000-8000



>

Model 7000 Features:

  • Eliminates slow grinding
  • No fumes - heat - smoke
  • No vibration

Milling type cutter uses 1/2 inch square carbide inserts

Radius cutters available for edge rounding perfect for cleaning up box corner welds or to prevent paint chipping on structural steel

Model 8000 Features

  • Ideal for weld preparation
  • Works plate and structural steel as thin as 3/16 inch for clean burr-free edges
  • Variable angle 15-45
  • Adjustable depth of cut
  • Works most materials machinable with carbide such as mild steel, aluminum and stainless steel
  • Self supporting on the work piece
  • Can be inverted to work the lower edge of plates
  • Specifically designed heavy duty motor
  • Using optional cutter head, radius edges can be made easily
  • V-Block design assures consistent edge quality
SPECIFICATIONS
Bevel-Mill Model 7000 Model 8000
Minimum Work Piece Thickness 1/8 inch - 3mm 1/8 inch - 3mm
Minimum Bevel 0 0
Maximum Bevel (B) 3/8 inch - 9.5mm 7/8 inch - 20.6mm
Bevel Angle 15 - 45 degree 15 - 45 degree
V-Block Length 8 inch - 200mm 8 inch - 200mm
Number Of Inserts 5 10
Motor 1/2hp, 110V 1hp, 110V
Weight 26lbs - 11.8kg 36lbs - 16.3kg
Heck 7000 & 8000 Bevel Mills
7000 Bevel Mill
8000 Bevel Mill
410 Replacement carbide insert C-5 grade
410 TCN Titanium coated carbide insert



Heck Bevel-Mill Model 9000

Heck Bevel-Mill Model 9000

Features

  • World's most powerful plate beveler
  • Faster feed rates
  • Comfortable cushioned handles
  • Uses 5/8 inch square carbide inserts
SPECIFICATIONS
Bevel-Mill Model 9000
Minimum workpiece thickness 1/8 inch - 3mm
Minimum bevel 0
Maximum bevel (B) 1 1/4 inch - 32mm
Bevel Angle 15 - 45
V-block length 8 3/4 inch - 219mm
Number of inserts 10
Motor 1 1/2hp, 110V
Weight 50lbs - 24kg
Heck 9000 Bevel Mill
9000 Bevel Mill
625 Replacement carbide insert for Model 9000
625 TCN Titanium coated insert form Model 9000



3000
HECK MODEL 3000 BEVEL MILL 3/16 MAXIMUM BEVEL (WHT = 14 LBS)
Mfg. item #: 3000
HEC3000
Ships FREE via UPS to lower 48 states.5
$2,495.00

481
410
HECK - CARBIDE INSERT C-5 GRADE (10 PK) FOR USE WITH BEVEL MILL 4000, 5000, 7000, 8000, VA-400 (SOLD IN A PACK OF 10 EACH)
Mfg. item #: 410
HEC410
FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.20
$79.69

481
410-TCN
TITANIUM COATED CARBIDE INSERT (10 PK) - FOR USE WITH BEVEL MILL 4000, 5000, 7000, 8000, VA-400 ** PACKAGE QUANTITY = 10 PCS
Mfg. item #: 410-TCN
HEC410-TCN
FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.20
Call for Price

876
WS410
Mfg. item #: WS410
HECWS410
FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.20
$116.72

481
5000
HECK MODEL 5000 BEVEL MILL 5/16 MAXIMUM BEVEL (WHT = 19 LBS)
Mfg. item #: 5000
HEC5000
Ships FREE via UPS to lower 48 states.5
$1,483.00

481
4000
HECK MODEL 4000 BEVEL MILL 3/4 MAXIMUM BEVEL (WHT = 22 LBS)
Mfg. item #: 4000
HEC4000
Ships FREE via UPS to lower 48 states.5
$2,000.00

481
7000
HECK MODEL 7000 BEVEL MILL 3/8 MAXIMUM BEVEL (WHT = 36 LBS)
Mfg. item #: 7000
HEC7000
Ships FREE via UPS to lower 48 states.5
$1,655.00

481
8000
HECK MODEL 8000 BEVEL MILL 7/8 MAXIMUM BEVEL (WHT = 44 LBS)
Mfg. item #: 8000
HEC8000
Ships FREE via UPS to lower 48 states.5
$2,129.00

481
410 TCN
HECK - TITANIUM COATED CARBIDE INSERT (10 PK) FOR USE WITH BEVEL MILL 4000, 5000, 7000, 8000, VA-400 (SOLD IN A PACK OF 10 EACH)
Mfg. item #: 410 TCN
HEC410 TCN
FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.20
$91.88

481
9000
HECK MODEL 9000 BEVEL MILL 1 1/4 MAXIMUM BEVEL (WHT = 60 LBS)
Mfg. item #: 9000
HEC9000
lease to own for as little as:$52 per month!
Ships FREE via UPS to lower 48 states.5
$2,587.00

481
625
HECK - CARBIDE INSERT FOR MODEL 9000 (10 PK) FOR USE WITH BEVEL MILL 9000 (SOLD IN A PACK OF 10 EACH)
Mfg. item #: 625
HEC625
FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.20
$120.94

481
625 TCN
HECK - TITANIUM COATED CARBIDE INSERT FOR MODEL 9000 (10 PK) FOR USE WITH BEVEL MILL 9000 (SOLD IN A PACK OF 10 EACH)
Mfg. item #: 625 TCN
HEC625 TCN
FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.20
$149.06

481
