JET VBS Vertical Bandsaws



VBS-1408, 14 VERTICAL BANDSAW VBS-1610, 16 VERTICAL BANDSAW VBS-2012, 20 VERTICAL BANDSAW VBS-3612, 36 VERTICAL BANDSAW
VBS-1408, 14 inch
VERTICAL BANDSAW 		VBS-1610, 16 inch
VERTICAL BANDSAW 		VBS-2012, 20 inch
VERTICAL BANDSAW 		VBS-3612, 36 inch
VERTICAL BANDSAW

jet 2 year warranty logo



wmh414483 VBS-1408, 14" Vertical Bandsaw

The Jet 14 inch Vertical Bandsaw, 1HP, 115/230V, 1 Ph, 115/230V
has a 2 Year warranty

The line of JET Vertical Bandsaws offers machine and fabrication professionals all the power and precision in a package that meets their individual specifications. An exclusive gear box design permits variety of cutting applications. Features you've come to expect, backed by the industry-leading JET Two Year Warranty



  • 1/4inch x 14/18VT Bi-metal blade
  • Bi-Metal blade welder, grinder, and cutter
  • Blade and tire cleaning brush
  • Blade welder, grinder, and cutter
  • Easy to read blade tension indicator
  • Heavy-duty bandsaw, can handle large production pieces on its extra-large table
  • Multi-tilting worktable
  • Variable speeds provide proper adjustments for high efficiency cutting



Detailed Specifications
Part Number 414483
Blade Length (in.) 1/2 X 114
Blade Size (in.) 1/8 - 1/2
Blade Speeds (SFPM) 82 - 330
Blade Width (Min-Max/ in.) 1/8 - 1/2
Brand Jet
Cutting Capacity Height (in.) 8
Height 71.5 inch
Length 26 inch
Model Number VBS-1408
Motor 1HP, 115/230V, 1Ph, Prewired 115V
Net Weight 643 pound
Overall Dimensions 34 x 24 x 68-1/2 inch
Table Height at 90 Degrees (in.) 39
Table Size (in.) 20 x 20
Table Tilt (deg.) 8 F & B, 12 L & 15 R
Throat Depth (in.) 14
Welder (KVA) 1.5 KVA
Width 36 inch





414485 VBS-1610, 16 inch Vertical Bandsaw has a 2 Year warranty
  • Heavy-duty, completely enclosed steel frame
  • Multi-tilting worktable
  • Easy to read blade tension indicator
  • Variable speeds provide proper adjustments for high efficiency cutting
  • Bi-Metal blade welder, grinder and cutter
  • Worklamp
  • Chip blower
  • Blade and tire cleaning brush
  • Set of tools
  • 1/4 inch x 14/18VT Bi-Metal blade
Detailed Specifications
Part Number 414485
Blade Speeds (SFPM) 82 - 3,950
Height Capacity (Max.) (In.) 10
Throat Capacity (In.) 15-1/2
Table Size (L x W) (In.) 22 x 24
Table Tilt (Deg.) 8 F & B, 12 L & 15 R
Blade Length (In.) 123-1/2
Blade Width (Min.-Max.) (In.) 1/8 - 5/8
Table Height (In.) 40
Motor (HP) 2 HP, 230/460V, 3Ph
Overall Dimensions (L x W x H) (In.) 37 x 28 x 72-1/2
Weight (Lbs.) 944
Height 78.0000
Length 38.5000
Weight 944.0000
Width 29.5000



/store/cms//590.jpeg VBS-2012, 20 inch Vertical Bandsaw has a 2 Year warranty
  • Heavy-duty, completely enclosed steel frame
  • Multi-tilting worktable
  • Easy to read blade tension indicator
  • Variable speeds provide proper adjustments for high efficiency cutting
  • Bi-Metal blade welder, grinder and cutter
  • Worklamp
  • Chip blower
  • Blade and tire cleaning brush
  • Set of tools
  • 1/4 inch x 14/18VT Bi-Metal blade
Detailed Specifications
Part Number 414482
Blade Speeds (SFPM) 65 - 3,280
Height Capacity (Max.) (In.) 12
Throat Capacity (In.) 20
Table Size (L x W) (In.) 24 x 22-1/2
Table Tilt (Deg.) 8 F & B, 15 R & 12 L
Blade Length (In.) 156-1/2
Blade Width (Min.-Max.) (In.) 1/8 - 1
Table Height (In.) 39-1/2
Motor (HP) 2 HP, 230/460V, 3Ph
Overall Dimensions (L x W x H) (In.) 42 x 30 x 79
Weight (Lbs.) 1,244
Height 84.0000
Length 45.0000
Weight 1244.0000
Width 34.0000



414470 Jet VBS-3612 36 Inch Vertical Bandsaw VBS-3612, 36 inch Vertical Bandsaw has a 2 Year warranty
  • Heavy-duty bandsaw, can handle large production piecies on its extra large twin tables
  • Three wheel system for cutting wide pieces
  • Two-Speed transmission and variable speed allow for a wide range of blade speeds
  • Heavy-duty, completely enclosed steel frame
  • Multi-tilting worktables
  • Easy to read blade tension indicator
  • Bi-Metal blade welder, grinder and cutter
  • Worklamp
  • Chip blower
  • Blade and tire cleaning brush
  • Rip Fence
  • Set of tools
  • 1/4 inch x 14/18VT Bi-Metal blade
Detailed Specifications
Part Number 414470
Blade Speeds (SFPM) 50 - 4,925
Height Capacity (Max.) (In.) 12
Throat Capacity (In.) 36
Table Size (L x W) (In.) 23-5/8 x 27-1/2, 17-3/4 x 27-1/2
Table Tilt (Deg.) 10 L, 45 R
Blade Length (In.) 197
Blade Width (Min.-Max.) (In.) 1/8 - 1
Table Height (In.) 40
Motor (HP) 3 HP, 230/460V, 3Ph
Overall Dimensions (L x W x H) (In.) 69 x 32 x 81
Weight (Lbs.) 1,760
Height 84.0000
Length 67.0000
Weight 2014.0000
Width 34.5000



jet 2 year warranty logo 2 YEAR WARRANTY AND SERVICE
WMH Tool Group, Inc., warrants every product it sells. If one of our tools needs service or repair, one of our Authorized Service Centers located throughout the United States can give you quick service. In most cases, any of these WMH Tool Group Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or perform routine maintenance and major repair on your Jet tools. For the name of an Authorized Service Center in your area call 1-800-274-6848.



JT9-414483
VBS-1408, 14 VERTICAL BANDSAW, SHIPS LTL TRUCK FREIGHT, MADE IN TAIWAN, WGT = 643 LBS

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS ITEM ** FREE FREIGHT & FREE RESIDENTIAL, LIFTAGTE & DELIVERY APPOINTMENT WHEN REQUESTED: NO HANDLING FEES
Mfg. item #: JT9-414483
WMH414483
lease to own for as little as:$117 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$6,049.00

105
JT9-414485
VBS-1610, 16 VERTICAL BANDSAW, SHIPS LTL TRUCK FREIGHT, MADE IN TAIWAN, WGT = 944 LBS

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS ITEM ** FREE FREIGHT & FREE RESIDENTIAL, LIFTAGTE & DELIVERY APPOINTMENT WHEN REQUESTED: NO HANDLING FEES
Mfg. item #: JT9-414485
WMH414485
lease to own for as little as:$169 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
NEW ITEM
$8,729.00

105
JT9-414482
VBS-2012, 20 VERTICAL BANDSAW --- WHILE SUPPLIES LAST, SHIPS LTL TRUCK FREIGHT, MADE IN TAIWAN, WGT = 1244 LBS

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS ITEM ** FREE FREIGHT: NO HANDLING FEES
Mfg. item #: JT9-414482
WMH414482
lease to own for as little as:$224 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
NEW ITEM
$11,649.00

105
JT9-414470
VBS-3612, 36 VERTICAL BANDSAW 3PH, 230V, TRUCK FREIGHT - DOCK REQUIRED, MADE IN TAIWAN, WGT = 2014 LBS

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS ITEM ** FREE FREIGHT: NO HANDLING FEES
Mfg. item #: JT9-414470
WMH414470
lease to own for as little as:$314 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$16,629.00

105
